230V EC 200mm 500W Durable Ventilation Single Inlet Impeller Centrifugal Blower with Scroll Housing
1. 200mm 2. IP44 protection level 3. Aluminum alloy motor with Galvanized Steel Sheet impeller, fashion design. 4. Using Ball bearing, working life more than 50,000 hours
EC 200mm Centrifugal Fan Forward Curved Blower Single Double Inlet Impeller Product Description
The EC 200mm Centrifugal Fan Forward Curved Blower is a high-performance, energy-efficient fan designed for various ventilation and air movement applications. This fan features a forward curved impeller and is available in both single and double inlet configurations, offering flexibility and versatility for different system requirements.
Key Features
EC Motor Technology: The fan is equipped with an EC (Electronically Commutated) motor, which provides superior efficiency and reliability compared to traditional AC motors.
Forward Curved Impeller: The forward curved impeller design ensures high airflow and static pressure, making it ideal for applications requiring significant air movement.
Speed Control: The fan supports 0-10VDC or PWM speed control, allowing for precise adjustment of airflow to meet specific needs.
Protection Features: It includes locked-rotor protection, reverse polarity protection, thermal protection, and a soft start function to ensure long-term reliability.
Durability: Constructed with high-quality materials, including PA plastic and glass fiber for the impeller, the fan is designed for long-lasting performance.
Low Noise Operation: The fan is engineered to operate quietly, minimizing noise levels while maintaining high performance.
EC 200mm Centrifugal Fan Forward Curved Blower Single Double Inlet Impeller Product Description
The EC 200mm Centrifugal Fan Forward Curved Blower is a high-performance, energy-efficient fan designed for various ventilation and air movement applications. This fan features a forward curved impeller and is available in both single and double inlet configurations, offering flexibility and versatility for different system requirements.
Key Features
EC Motor Technology: The fan is equipped with an EC (Electronically Commutated) motor, which provides superior efficiency and reliability compared to traditional AC motors.
Forward Curved Impeller: The forward curved impeller design ensures high airflow and static pressure, making it ideal for applications requiring significant air movement.
Speed Control: The fan supports 0-10VDC or PWM speed control, allowing for precise adjustment of airflow to meet specific needs.
Protection Features: It includes locked-rotor protection, reverse polarity protection, thermal protection, and a soft start function to ensure long-term reliability.
Durability: Constructed with high-quality materials, including PA plastic and glass fiber for the impeller, the fan is designed for long-lasting performance.
Low Noise Operation: The fan is engineered to operate quietly, minimizing noise levels while maintaining high performance.
