FW3G200-24GC-90导风筒
Fanova
The FW3G200-24GC-90 is a high-performance wall-mounted axial flow fan engineered for space-efficient industrial ventilation and dust removal systems. Designed with a galvanized steel impeller and integrated wall ring, this 24V DC fan delivers exceptional airflow of 1,205 m³/h (709 CFM) at 250 Pa static pressure, making it ideal for confined industrial environments where reliable air circulation and debris control are critical. Its compact 200mm size and low-voltage operation (16~28VDC) ensure versatility across multiple industrial applications, while the IP44 protection level and 50,000-hour lifespan guarantee long-term durability in harsh conditions.
Parameter | Unit | Value |
Nominal Voltage | V DC | 24 |
Voltage Range | V DC | 16 ~ 28 |
Current Draw | A | 2.5 ± 10% |
Speed (RPM) | min⁻¹ | 3000 ± 5% |
Power Consumption | W | 60 ± 10% |
Sound Pressure Level | dB(A) | 62 ± 5% |
Max. Air Flow | CFM / m³/H | 709.14 / 1205 |
Max. Static Pressure | In.wg / Pa | 1.0 / 250 |
Insulation Class | ~ | Class B |
Degree of Protection | ~ | IP44 |
Control Input | ~ | 0~10VDC / PWM |
Signal Output | ~ | FG (Tach output) |
Life Expectance (L10) | Hours | 50,000 (40℃, 15%~65%RH) |
Operating Temperature Range | ℃ | -25 ~ 60 |
The integrated mounting ring enables seamless surface installation without external brackets, saving space in tight industrial setups. Its counter-clockwise rotation prevents debris accumulation in wall-adjacent applications—critical for dust removal systems—while the die-cast aluminum wall ring offers corrosion resistance for long-term industrial use.
Equipped with a 7-blade galvanized steel impeller, this high speed axial flow fan withstands harsh industrial environments, including exposure to dust and minor moisture. It maintains consistent performance across voltage fluctuations (16~28VDC) and operates at a maximum 60W power consumption, balancing efficiency and power for demanding ventilation tasks.
Simplify installation with standard 0~10VDC/PWM speed control and FG (tachometer) output (4 pulses/revolution). The fan’s 4-wire configuration (#20AWG) supports quick integration into industrial control systems, while the tachometer output enables real-time performance monitoring—essential for automated dust removal and ventilation setups.
Built with ball bearings and an IP44 protection rating, this 24V DC axial fan delivers a 50,000-hour L10 lifespan in temperatures ranging from -25℃ to 60℃. It features comprehensive protection mechanisms: motor current limitation, soft starting, under/over voltage detection, thermal overload protection, locked-rotor protection, and reverse polarity protection—ensuring reliability in rugged industrial conditions.
This versatile high speed axial flow fan excels in multiple industrial scenarios:
Machine enclosure cooling for equipment operating in dusty environments
Control panel ventilation to prevent overheating of sensitive electronics
Cabinet exhaust systems for debris and heat removal
Solar-powered ventilation setups (compatible with low-voltage renewable energy systems)
Compact HVAC units requiring efficient air circulation and dust control
Its dust-resistant design and high airflow make it a top choice for dust removal systems in manufacturing, warehousing, and processing facilities.
Counter-clockwise. This design prevents debris buildup against walls, optimizing performance for dust removal applications.
16VDC. Performance degrades if the voltage drops below this threshold—ensure compatibility with your power system.
Die-cast aluminum. It offers corrosion resistance, making it suitable for long-term industrial use.
Yes. The 4 pulses/revolution tachometer output works with standard PLC tachometer inputs for seamless system integration.
